11-1/4" Dual Stage Clutch Unit - New

Daiken style clutch w/ a full backplate & coil springs. This clutch requires 95mm mounting bolts.Interchanges w/ K35788-25104U which has a Belleville washer & split backplate.Includes: PPA, K35820-25133 Captive Trans. Disc & K32590-14300 (Flywheel Side PTO Disc)The K35555-25100NU 11-1/4" Dual Stage Clutch Unit - New fits equipment brands such as: Kubota

Manufacturer: Hy-Capacity

SKU: K35555-25100NU

$578.09

Qty:

+ -

Notes:

All prices are USD. If imported into Canada/Internationally there will be brokerage costs collected by the carrier. Check the"Canada/World" link at the top of the page for more info. Please note that Hy-Capacity items can not be shipped to Canada / International.

Specifications

Products specifications

Attribute name	Attribute value
Size	11-1/4"
PPA Levers	6
PPA Springs	18 Coil Springs
Captive Disc Spec	Woven; 1-9/16" 14 Spline Hub; Spring Center
Flywheel Disc Spec	Woven; 15/16" 10 Spline Hub; Solid Center
New/Reman	New
Sold As	Each

Products specifications

Attribute name	Attribute value
Size	11-1/4"
PPA Levers	6
PPA Springs	18 Coil Springs
Captive Disc Spec	Woven; 1-9/16" 14 Spline Hub; Spring Center
Flywheel Disc Spec	Woven; 15/16" 10 Spline Hub; Solid Center
New/Reman	New
Sold As	Each

Product tags

35555-25100 (1)
,
35830-25102 (1)
,
35830-25104 (1)
,
35555-25102 (1)

Use On Below Models (Click to expand)

Kubota

Tractor: M4950 M4950DT M4950DTS M4950S M5030 w/ coil springs & full backplate M5030DT M5030SU w/ coil springs & full backplate M5030SUMDT M5950 M5950C M5950DT M5950DTC M5950DTS M5950S M6030 M6030DT M6030DTN M6030DTNB M7030DTBN M7030N M7030SU M7030SUDT M7500 M7500ACL M7500DT M7500DTACL
