Picture of Clutch Alignment Tool, .667" Pilot Dia., 1" 10 Spline, 1-9/16" 14 Spline

Picture of Clutch Alignment Tool, .667" Pilot Dia., 1" 10 Spline, 1-9/16" 14 Spline

Picture of Clutch Alignment Tool, .667" Pilot Dia., 1" 10 Spline, 1-9/16" 14 Spline

Clutch Alignment Tool, .667" Pilot Dia., 1" 10 Spline, 1-9/16" 14 Spline

Be the first to review this product

This tool is for installation purposes & not returnable.

Manufacturer: Hy-Capacity

SKU: 8301890

Vendor: Granit

Availability:

In stock

$32.78

Qty:

+ -

Notes:

All prices are USD. If imported into Canada/Internationally there will be brokerage costs collected by the carrier. Check the"Canada/World" link at the top of the page for more info. Please note that Hy-Capacity items can not be shipped to Canada / International.

Specifications

Products specifications

Attribute name	Attribute value
Dimensions	Pilot Dia = .667; 1st Spline = 1" 10 Spline; 2nd Spline = 1-9/16" 14 Spline
New/Reman	New
Sold As	Each
Warranty	1 Year
Pilot Dia.	.667"

Products specifications

Attribute name	Attribute value
Dimensions	Pilot Dia = .667; 1st Spline = 1" 10 Spline; 2nd Spline = 1-9/16" 14 Spline
New/Reman	New
Sold As	Each
Warranty	1 Year
Pilot Dia.	.667"

Use On Below Models (Click to expand)

Allis Chalmers

Tractor: 5040 5045 5050 6060 6070

Case IH

Tractor: JX1060C JX1070C JX1070N JX1075C JX1075V JX1085C JX1095C JX1095N JX55 JX60 JX65 JX70 JX70U JX75 JX80 JX85 JX90 JX95 Works w/ 11" Dual Stage Clutch Only

Farmtrac

Tractor: 410 530 550

Ford

Tractor: 3010S 4010S 4030 4230 4430 5010S 5530 6530

Hesston-Fiat

Tractor: 680 680DT 70-66 80-66

Landini

Tractor: 5500 6060 6070

Long

Tractor: 2360 2460 2510 2610 310 360 445 460 510 560 610 680

Minneapolis Moline

Tractor: G450

New Holland

Tractor: 5635 Powerstar 90 w/ Tier 4B - Mechanical Tractor, Yr. 11/17 thru 09/18 T4.100F T4.100LP T4.100V T4.105F T4.105V Power Shuttle T4.65V T4.75F T4.75V T4.80F T4.80LP T4.80V T4.85 T4.85F T4.85V T4.90 T4.90F T4.90LP T4.90V T4.95F T4.95V T4020 Power Shuttle T4020V Power Shuttle T4030 Power Shuttle T4030F Power Shuttle T4030N T4030V Power Shuttle T4040 Power Shuttle T4040F Power Shuttle T4040N T4040V Power Shuttle T4050 Power Shuttle T4050F Power Shuttle T4050N T4050V Power Shuttle T4060F T4060N T4060V TD4.80F w/ Tier 4B - Mechanical Tractor, Yr. 11/17 thru 09/18 TD4.90F TD4030F TD4040F Mechanical Shuttle TD5010 TD5020 TD5030 TD5050 TD60D TD70D TD80D TD85F w/ Tier 3 - Upgrade Tractor, Start Yr. 07/15 & Up TD85F TD90D TD90F TD95D Works w/ 11" Dual Stage Clutch Only TN55 TN55D TN55S TN60A TN60DA TN60SA TN60VA TN65 TN65D TN65F TN65S TN65V TN70 TN70A TN70D TN70F TN70NA TN70S Power Shuttle TN70VA TN75 TN75A TN75D TN75F TN75FA TN75S Power Shuttle TN75V TN75VA TN80F TN85A TN85DA TN85FA TN85SA TN90F TN95A TN95DA TN95F TN95FA TN95NA TN95VA TT50A TT55 TT60A TT65 TT75 TT75A Workmaster 45 Workmaster 50 Workmaster 55 Workmaster 60 Workmaster 65 Yrs. Prior to 9/18, Will Not Fit Tier 4A Machines Workmaster 75 Yrs. Prior to 9/18, Will Not Fit Tier 4A Machines

Oliver

Tractor: 1255 1265 1270 1355 1365 1370

White

Tractor: 2-50 2-60 700
