High Compression Major Overhaul Kit, John Deere 4-270D Diesel Engine

This Overhaul Kit contains Pistons made of hypereutectic aluminum alloy, which makes the piston inherently stronger. It is also more resistant to expansion and contraction, as well as scuff and corrosion resistant. Efficiency improves due to a better seal between the rings and cylinder wall. Includes:

(4) ##HCTRE23173HC## Cylinder Kits
(4) ##HCTAR45723## Rod Bearings
(4) ##HCTAR49243## Main Bearings
(1) ##HCTAR49242## Thrust Bearing
(1) ##HCTAR53033## Overhaul Gasket Set
(1) ##HCNAR49025## Front Crank Seal
(1) ##HCNRE520036## Rear Crank Seal
(4) ##HCTR30939## Piston Pin Bushings
(3) ##HCTR46903## Cam Bushings
(8) ##HCTR66452## Connecting Rod Bolts

Manufacturer: Hy-Capacity

SKU: HCTRG17899HC

Availability:

Out of stock

$1,720.35

Qty:

+ -

Notes:

All prices are USD. If imported into Canada/Internationally there will be brokerage costs collected by the carrier. Check the"Canada/World" link at the top of the page for more info. Please note that Hy-Capacity items can not be shipped to Canada / International.

Specifications

Products specifications

Attribute name	Attribute value
Engine Manufacturer	John Deere
Block Marked	R26160, R32020, R40850, R46385, R26160, R32020, R40850, R46385
Connecting Rod Marked	R26047, R52225, R58880, R69923, R26047, R52225, R58880, R69923
Engine Notes	1.50" Piston Pin Diameter, Bore: 4.250", Naturally Aspirated, Original Block, 1.50" Piston Pin Diameter, Bore: 4.250", Naturally Aspirated, Original Block
Piston Pin Dia.	1.500"
Engine CID	254
Fuel Type	Diesel
Cylinder Count	4
Bore	4.250"
Stroke Length	4.750"
Rod Journal Dimensions	2.9980" - 2.9990"
Main Journal Dimensions	3.3715-3.3725"
New/Reman	New
Sold As	Each
Warranty	1 Year

Products specifications

Attribute name	Attribute value
Engine Manufacturer	John Deere
Block Marked	R26160, R32020, R40850, R46385, R26160, R32020, R40850, R46385
Connecting Rod Marked	R26047, R52225, R58880, R69923, R26047, R52225, R58880, R69923
Engine Notes	1.50" Piston Pin Diameter, Bore: 4.250", Naturally Aspirated, Original Block, 1.50" Piston Pin Diameter, Bore: 4.250", Naturally Aspirated, Original Block
Piston Pin Dia.	1.500"
Engine CID	254
Fuel Type	Diesel
Cylinder Count	4
Bore	4.250"
Stroke Length	4.750"
Rod Journal Dimensions	2.9980" - 2.9990"
Main Journal Dimensions	3.3715-3.3725"
New/Reman	New
Sold As	Each
Warranty	1 Year

Product tags

HCR17899HC (1)
,
HCRP-359 (1)
,
HCRP-729 (1)
,
HCRP-729-10 (1)
,
HCRP-729-30 (1)
,
HCRP729 (1)
,
TRG17899HC-10/STD (1)
,
HCRP-360 (1)
,
RP729 (1)
,
TRG17899HC (1)
,
TRG17899HC-20/10 (1)
,
HCAVJDHC270EM (1)
,
HCRP-729-20 (1)
,
TRG17899HCNB (1)
,
HOK-JDHC270EM (1)
,
TRG17899HC-10/10 (1)
,
TRG17899HC-10/20 (1)
,
TRG17899HC-20/20 (1)
,
HCRRP729 (1)

Use On Below Models (Click to expand)

John Deere

Engine: 400 Series Engine 4.270D

LOADER BACKHOE: 500 4270 Diesel, S/N <-280,000, w/ Original Block 500A 4270 Diesel, S/N <-280,000, w/ Original Block

TRACTOR: 3010 4270 Diesel, S/N <-280,000, w/ Original Block 3020 4270 Diesel, S/N <-280,000, w/ Original Block
