LED-5602 Hi-Lo

Be the first to review this product

LED-5602 - 60 watt Hi-Lo for JD tractors and more. Ships with pins installed on the wires, and 3 different connectors for different applications. John Deere part # AL174332 (RHT) AL174344 (LHT), AL204952 (LHT), AL204951 (RHT).

Manufacturer: Larsen Lights

SKU: LL0621

Availability:

173 in stock

$67.00

Qty:

+ -

Notes:

All prices are USD. If imported into Canada/Internationally there will be brokerage costs collected by the carrier. Check the"Canada/World" link at the top of the page for more info. Please note that Hy-Capacity items can not be shipped to Canada / International.

Overview

LED-5602 - 60 watt Hi-Lo for JD tractors and more.

Ships with pins installed on the wires, and 3 different connectors for different applications:

Delphi 12129615, 150 Series Metri-Pack Connector, 3 Way
Delphi 12162000, 150 Series Metri-Pack Connector, 2 Way
Delphi Metri-Pack 150 2 Way Gray Sealed Male Connector

Specifications :

. LED Power: 60 Watt Bridgelux (30 watt high beam, 30 watt low beam)
. Operating Volt: 10-30 Volt DC
. Beam pattern: High/Low beam
. Light Output: High beam 2200lm + Low beam 2200lm
. Color Temperature: 5700K
. Operation Temperature: -40℃~80℃
. Waterproof Rate: IP68
. Material: diecast aluminum housing, stainless steel bracket
. Lens: PC
. Life Time: about 50,000 hours
. EMC: ECE R10, CISPR 25 Class 4

Wiring:

High Beam (Red)

Low Beam (Blue)

Gound Line (Black)

Hi-Lo, LED5602, 575225D1, 72380647, 72380644, John Deere, AL174332, (RHT) AL174344, (LHT), AL204952, (LHT), AL204951, (RHT), X830160066000, 47697493, 47697493, 1A3 996 002-191

LED-5602 - 60 watt Hi-Lo for JD tractors and more.

Ships with pins installed on the wires, and 3 different connectors for different applications:

Delphi 12129615, 150 Series Metri-Pack Connector, 3 Way
Delphi 12162000, 150 Series Metri-Pack Connector, 2 Way
Delphi Metri-Pack 150 2 Way Gray Sealed Male Connector

Specifications :

Wiring:

High Beam (Red)

Low Beam (Blue)

Gound Line (Black)

Hi-Lo, LED5602, 575225D1, 72380647, 72380644, John Deere, AL174332, (RHT) AL174344, (LHT), AL204952, (LHT), AL204951, (RHT), X830160066000, 47697493, 47697493, 1A3 996 002-191

Product tags

Sealed Beam (7)
,
hi-lo (42)

Use On Below Models (Click to expand)

John Deere

Tractor: 5075M 5090M 5090R 5100M 5100R 5115M 5115R 5125R 6090M 6095MC 6095RC 6100M 6105M 6105MC 6105R 6105RC 6110M 6110R 6115M 6115MC 6115R 6115RC 6120M 6120R 6125M 6125R 6130M 6130R 6135M 6135R 6140M 6140R 6145M 6145R 6150M 6150R 6150R, 6150RH 6155M 6155M, 6155MH 6155R 6155R, 6155RH 6170M 6170R 6175M 6175R 6190R 6195M 6195R 6210M 6210R 6215R 6230 6230R 6250R 6330 6430 6530 6534 6630 6830 6930 7130 7230 7330 7430 7530
