Major Overhaul Kit, Cummins 4BTA 3.9 Diesel Engine, Std. Pistons

Machined split rods only.

Includes: • (4) ##HCC3802747## Piston & Rings • (8) ##HCC3901170## Rod Bearings • (1) ##HCC3802010## Main Bearing Set • (1) ##HCC3804896## Head Gasket Set • (1) ##HCC3802375## Conversion Gasket Set • (4) ##HCC4891178## Piston Pin Bushings • (1) ##HCC3901306## Cam Bushings • (1) ##HCC3940059## Cam Bushings

Manufacturer: Hy-Capacity

SKU: HCCOK27474

Vendor: Granit

Availability:

In stock

$627.24

Qty:

+ -

Notes:

All prices are USD. If imported into Canada/Internationally there will be brokerage costs collected by the carrier. Check the"Canada/World" link at the top of the page for more info. Please note that Hy-Capacity items can not be shipped to Canada / International.

Specifications

Products specifications

Attribute name	Attribute value
Engine Manufacturer	Cummins
Engine Notes	Emission Certified
Piston Marked	8673, 8674, 8675, 8673, 8674, 8675
Engine CID	239
Fuel Type	Diesel
Cylinder Count	4
Bore	4.020"
Stroke Length	4.720"
Rod Journal Dimensions	2.7160" - 2.7170"
Main Journal Dimensions	3.2672" - 3.2682", 3.2672-3.2682"
New/Reman	New
Sold As	Each
Warranty	1 Year
Dimensions	Standard

Products specifications

Attribute name	Attribute value
Engine Manufacturer	Cummins
Engine Notes	Emission Certified
Piston Marked	8673, 8674, 8675, 8673, 8674, 8675
Engine CID	239
Fuel Type	Diesel
Cylinder Count	4
Bore	4.020"
Stroke Length	4.720"
Rod Journal Dimensions	2.7160" - 2.7170"
Main Journal Dimensions	3.2672" - 3.2682", 3.2672-3.2682"
New/Reman	New
Sold As	Each
Warranty	1 Year
Dimensions	Standard

Product tags

1965 (23)
,
1966 (23)
,
1967 (23)
,
2109 (23)
,
2142 (23)
,
2144 (23)
,
2302 (23)
,
2351 (23)
,
2359 (23)
,
2478 (23)
,
2528 (23)
,
2623 (23)
,
2672 (23)
,
2808 (23)
,
2857 (23)
,
2881 (23)
,
COK2747/4NB (1)
,
HOK-CUM390TMA (3)
,
K73342186 (1)
,
COK2747/4 (1)
,
HCK73342186 (1)

Use On Below Models (Click to expand)

AGCO

Tractor: LT70 Cummins 4T390 Diesel LT85 Cummins 4T390 Diesel

Allis Chalmers

Tractor: 8745 Cummins 4T390 Diesel, From Tractor S/N J24,131 8765 Cummins 4T390 Diesel, From Eng. S/N 21,414,081

Cummins

Engine: 3.9 Engine Cummins Diesel Engine, 4BTA 3.9
