Major Overhaul Kit, John Deere 4-239T; 4039T Diesel Engine, High Ring Piston

For engine 4239T use connecting rod #R80032, R113612, R122191 & piston #RE33115. For engine 4039T use connecting rod #R80032, R113612, R122191 & piston #RE19282, RE30250. If your connecting rod is marked R58979 or R51727, you MUST order ##HCTR74194## capscrews separately. Includes:
  • (4) ##HCTRE33115## Cylinder Kits
  • (4) ##HCTRE27348## Rod Bearings
  • (4) ##HCTRE27352## Main Bearings
  • (1) ##HCTAT21139## Thrust Bearing
  • (1) ##HCTRE501579## Overhaul Gasket Set
  • (1) ##HCTAR67942## Front Crank Seal
  • (1) ##HCNRE44574## Rear Crank Seal
  • (4) ##HCTR57451## Piston Pin Bushings
  • (1) ##HCTMX504## Grommet Kit
  • (6) ##HCTR57160## Balancer Shaft Bushing
  • (8) ##HCTR80033## Connecting Rod Bolts
  • (8) ##HCTRE31617## Valve Stem Seals
Manufacturer: Hy-Capacity
SKU: HCTRE54709
In stock
$1,161.00
+ -
Notes:

All prices are USD. If imported into Canada/Internationally there will be brokerage costs collected by the carrier. Check the"Canada/World" link at the top of the page for more info.  Please note that Hy-Capacity items can not be shipped to Canada / International.

Products specifications
Attribute name Attribute value
Engine Manufacturer John Deere
Connecting Rod Marked R113612
Engine Notes 1.625" Piston Pin Diameter, High Ring Piston, Turbocharged, 1.625" Piston Pin Diameter, High Ring Piston, Turbocharged
Piston Marked RE33115
Piston Pin Dia. 1.625"
Engine CID 239
Fuel Type Diesel
Cylinder Count 4
Bore 4.193"
Stroke Length 4.331"
Rod Journal Dimensions 2.7480" - 2.7488"
Main Journal Dimensions 3.1230-3.1240"
New/Reman New
Sold As Each
Warranty 1 Year
Products specifications
Attribute name Attribute value
Engine Manufacturer John Deere
Connecting Rod Marked R113612
Engine Notes 1.625" Piston Pin Diameter, High Ring Piston, Turbocharged, 1.625" Piston Pin Diameter, High Ring Piston, Turbocharged
Piston Marked RE33115
Piston Pin Dia. 1.625"
Engine CID 239
Fuel Type Diesel
Cylinder Count 4
Bore 4.193"
Stroke Length 4.331"
Rod Journal Dimensions 2.7480" - 2.7488"
Main Journal Dimensions 3.1230-3.1240"
New/Reman New
Sold As Each
Warranty 1 Year
