Major Overhaul Kit, John Deere 4270 Diesel Engine

Includes: • (3) ##HCABR46903## Camshaft Bushing • (1) ##HCABR26115## Camshaft Plug • (8) ##HCABR66452## Capscrews • (4) ##HCABRE23165## Cylinder Kits • (1) ##HCABAR49025## Front Crankshaft Seal & Sleeve • (4) ##HCABAR74814## Main Bearings • (1) ##HCABAR53035## Overhaul Gasket Set • (1) ##HCABRE22764## Rear Crankshaft Seal & Sleeve • (4) ##HCABAR45723## Rod Bearings • (4) ##HCABR30939## Rod Honable Bushing • (1) ##HCABAR77748## Thrust Bearing • (1) ##HCABAR77747## Thrust Washer Set

Manufacturer: Hy-Capacity

SKU: HCAB298

Availability:

In stock

$918.28

Qty:

+ -

Notes:

All prices are USD. If imported into Canada/Internationally there will be brokerage costs collected by the carrier. Check the"Canada/World" link at the top of the page for more info. Please note that Hy-Capacity items can not be shipped to Canada / International.

Specifications

Products specifications

Attribute name	Attribute value
Engine Manufacturer	John Deere
Block Marked	R40620
Connecting Rod Marked	R26047, R52225, R58880, R66923, R26047, R52225, R58880, R69923, R26047, R52225, R58880, R69923
Piston Marked	RE23168, RE40563, RE23168, RE40563
Piston Pin Dia.	1.500"
Engine CID	254
Fuel Type	Diesel
Cylinder Count	4
Bore	4.250"
Stroke Length	4.750"
Rod Journal Dimensions	2.9980" - 2.9990"
Main Journal Dimensions	3.3715" - 3.3725", 3.3715-3.3725"
New/Reman	New
Sold As	Each
Warranty	1 Year

Products specifications

Attribute name	Attribute value
Engine Manufacturer	John Deere
Block Marked	R40620
Connecting Rod Marked	R26047, R52225, R58880, R66923, R26047, R52225, R58880, R69923, R26047, R52225, R58880, R69923
Piston Marked	RE23168, RE40563, RE23168, RE40563
Piston Pin Dia.	1.500"
Engine CID	254
Fuel Type	Diesel
Cylinder Count	4
Bore	4.250"
Stroke Length	4.750"
Rod Journal Dimensions	2.9980" - 2.9990"
Main Journal Dimensions	3.3715" - 3.3725", 3.3715-3.3725"
New/Reman	New
Sold As	Each
Warranty	1 Year

Use On Below Models (Click to expand)

John Deere

LOADER BACKHOE: 500A John Deere 4270 Diesel, ESN 280001-> 500B John Deere 4270 Diesel, ESN 280001-> 500C John Deere 4270 Diesel, ESN 280001-> 510 John Deere 4270 Diesel, ESN 280001->

TRACTOR: 3020 John Deere 4270 Diesel, ESN 280001->
