Major Overhaul Kit, John Deere 6-619T Diesel Engine

Includes: • (6) ##HCTRE20291## Cylinder Kits • (6) ##HCTAR101271## Rod Bearings • (6) ##HCTAR101268## Main Bearings • (1) ##HCTAR101269## Thrust Bearing • (1) ##HCTAR89622## Thrust Washer Set • (1) ##HCTRE37416## Overhaul Gasket Set • (1) Front Crank Seal • (6) ##HCTR69045## Piston Pin Bushings • (1) ##HCTRE13310## Rear Crank Seal • (4) ##HCTR46903## Cam Bushings • (12) ##HCTR66453## Connecting Rod Bolts

Manufacturer: Hy-Capacity

SKU: HCTOK20291

Availability:

Out of stock

$4,011.47

Qty:

+ -

Notes:

All prices are USD. If imported into Canada/Internationally there will be brokerage costs collected by the carrier. Check the"Canada/World" link at the top of the page for more info. Please note that Hy-Capacity items can not be shipped to Canada / International.

Specifications

Products specifications

Attribute name	Attribute value
Engine Manufacturer	John Deere
Block Marked	R63199, R63199; R63912; R72130; R74123, R63912, R72130, R63199, R63912, R72130, R74123, R63199, R63912, R72130, R74123
Connecting Rod Marked	R63959
Engine Notes	2.000" Piston Pin Diameter, Curved Counterbore Relief, Turbocharged & Aftercooled, 2.000" Piston Pin Diameter, Curved Counterbore Relief, Turbocharged & Aftercooled
Piston Pin Dia.	2.000"
Engine CID	619
Fuel Type	Diesel
Cylinder Count	6
Bore	5.125"
Stroke Length	5.000"
Rod Journal Dimensions	3.4980" - 3.4990"
Main Journal Dimensions	3.7480" - 3.7490", 3.7480-3.7490"
New/Reman	New
Sold As	Each
Warranty	1 Year
