30 watt PAR-36 Flood, Frosted Lens

Be the first to review this product

High power PAR-36 size replacement LED light for the old style sealed beam halogen light. 6 x 5 watt CREE LED chips. Actual power use is around 22 watt, effective lumen around 1700. 60° Flood Beam. Note: It is a good practice to drill a few holes on top and bottom of the housing the light is mounted in, this will help the lights cool.

Manufacturer: Larsen Lights

SKU: LL0026

Availability:

582 in stock

$37.00

Qty:

+ -

Notes:

All prices are USD. If imported into Canada/Internationally there will be brokerage costs collected by the carrier. Check the"Canada/World" link at the top of the page for more info. Please note that Hy-Capacity items can not be shipped to Canada / International.

Overview

PAR-36 led bulb / light, 60° flood beam.

UV resistant PC lens.

Works as a replacement for the halogen sealed beam PAR-36 (4 3/8" bulb) used on many older tractors,

JD 30, 40 & 50 series IH and many others.

Bulb: 6 Pcs * 5W LED CREE XTE 5

Color Temperature: 5000k (White daylight)
60° flood beam
PC lens
Power: 30W rated, 19-20 watt used @ 12V
Operating Voltage:9-32V DC
Luminous:1700 effective measured by machine
Current: 1.8A @ 12V
Lifespan: 30,000Hours
Overvoltage protection
Back of housing has large cooling ribs for optimized heat dissipation
Size: 4.5" Dia. without housing.
IP67

HO Par36, HO Par-36, Par-36, Par36, High Output, High, Flood

PAR-36 led bulb / light, 60° flood beam.

UV resistant PC lens.

Works as a replacement for the halogen sealed beam PAR-36 (4 3/8" bulb) used on many older tractors,

JD 30, 40 & 50 series IH and many others.

Bulb: 6 Pcs * 5W LED CREE XTE 5

Color Temperature: 5000k (White daylight)
60° flood beam
PC lens
Power: 30W rated, 19-20 watt used @ 12V
Operating Voltage:9-32V DC
Luminous:1700 effective measured by machine
Current: 1.8A @ 12V
Lifespan: 30,000Hours
Overvoltage protection
Back of housing has large cooling ribs for optimized heat dissipation
Size: 4.5" Dia. without housing.
IP67

HO Par36, HO Par-36, Par-36, Par36, High Output, High, Flood

Product tags

PAR-36 (18)

Use On Below Models (Click to expand)

Allis Chalmers

Motor Grader: M60 Fender Lamp M70 Fender Lamp

Tractor: 170 Fender Lamp 175 Fender Lamp 180 Fender Lamp, Prior to S/N 12800 185 Fender Lamp 190 Fender Lamp 190XT III Fender Lamp 210 Fender Lamp 220 Fender Lamp 220FWA Fender Lamp 6040 Fender Lamp 6060 Fender Lamp 6080 Fender Lamp

Case

Tractor: 2090 Fender Lamp 2290 Fender Lamp 2390 Fender Lamp 2590 Fender Lamp 4490 Fender Lamp 4690 Fender Lamp 4890 Fender Lamp

Case IH

Combine: 1660 1680 1682

Tractor: 3220 Fender Lamp 3230 Fender Lamp 4210 Fender Lamp 4230 Fender Lamp 4240 Fender Lamp 495 North American Models 595 North American Models 995 Less Cab

David Brown

Tractor: 1190 Fender Lamp 1290 Fender Lamp 1390 Fender Lamp 1394 Fender Lamp 1490 Fender Lamp 1494 Fender Lamp 1690 Fender Lamp

Ford

Tractor: 230A Fender Lamp 231 Fender Lamp 2310 Fender Lamp 233 Fender Lamp 234 Fender Lamp 2600 Fender Lamp 2610 Fender Lamp 2810 Fender Lamp 2910 Fender Lamp 333 Fender Lamp 334 Fender Lamp 335 Fender Lamp 3600 Fender Lamp 3610 Fender Lamp 3910 Fender Lamp 4000 4100 Fender Lamp 4110 Fender Lamp 4200 4600 Fender Lamp 4610 Fender Lamp 5000 5110 Fender Lamp 515 Fender Lamp 5200 530A Fender Lamp 531 Fender Lamp 532 Fender Lamp 5600 Fender Lamp 5610 Fender Lamp 5700 Fender Lamp 5900 6410 U.K. Only 6600 Fender Lamp 6610 Fender Lamp 6700 Fender Lamp 6710 Fender Lamp 6810 7000 7200 7410 7600 Fender Lamp 7610 Fender Lamp 7700 Fender Lamp 7710 Fender Lamp 8000 Fender Lamp 8210 Fender Lamp 8530 Fender Lamp 8630 Fender Lamp 8700 Fender Lamp 8730 Fender Lamp 8830 Fender Lamp 9000 Fender Lamp 9700 Fender Lamp TW10 Fender Lamp TW15 Fender Lamp TW20 Fender Lamp TW25 Fender Lamp TW30 Fender Lamp TW35 Fender Lamp TW5 Fender Lamp

Tractor Loader Backhoe: 420 535 Fender Lamp

Wheel Loader: A62 European Models A625 European Models A64 European Models A66 European Models

Gleaner

Combine: R60 Use Where Applicable

International

Combine: 1420 1440 1460 1470 Hillside 1480 1482 303 Eff. S/N11764 315 402 Hillside 403 503 615 715 815 915

Cotton Harvester: 1400 95

Cotton Picker: 414 420 616 782

Tractor: 1026 1066 1086 1206 1256 1456 1466 1468 1486 1566 1586 1588 21026 21206 21256 21456 2400A 2404 2424 2444 248 2500A North American Models 2504 2544 2606 2656 2706 2756 2806 2826 2856 3088 3288 3388 340 3488 3588 3688 3788 384 404 4166 4186 424 4366 4386 444 North American Models 454 North American Models 4568 4586 460 464 Eff. S/N 109151 4786 484 504 5088 5288 544 5488 574 606 6388 656 6588 664 666 674 6788 684 686 706 7288 7488 756 786 806 826 856 886 966 986 Cub Cub 154 Lo-Boy Cub 185 Lo-Boy Hydro 100 Hydro 186 Hydro 70 Hydro 84 Hydro 86

Windrower: 201 275 375 4000 5000 5500 742 750

John Deere

Combine: 4400 Eff. S/N 201251 6600 6620 6622 7720 8820 9400 Auger light 9410 Auger light 9500 Auger light 9510 Auger light 9600 Auger light 9610 Auger light 9650 Auger light 9750 Auger light 9850 Auger light

Harvester: 5200 5400 5440 5460

Tractor: 2010 2030 2040 2140 2240 2350 2355 2440 2510 2520 2550 2555 2640 2750 2755 2840 2855N 2940 2950 2955 3010 3020 3020 3040 3020 3055 3140 3150 3155 3255 4000 4010 4020 4030 4040 4040S 4055 4055 4230 4240 4240S 4250 4255 4350 4430 4440 4450 4450 4455 4520 4555 4560 4620 4630 4640 4650 4755 4760 4840 4850 4955 4960 5010 5020 6030 7020 7520 8430 8440 8450 8560 8570 8630 8640 8650 8760 8770 8870 8960 8960 8970 9200 9200 9300 9300T 9400 9400T

Wheel Loader: 444D 544D 644D

Windrower: 2360

Massey Ferguson

Combine: 550 850 855 Eff. S/N 1696027544 8570 860 8780

Swather: 785

Tractor: 1080 Fender Lamp 1085 Fender Lamp 1100 Fender Lamp 1105 Fender Lamp 1130 Fender Lamp 1135 Fender Lamp 1150 Fender Lamp 1155 Fender Lamp 135 w/ Flat Top Fender 150 Fender Lamp 1500 Fender Lamp 1505 Fender Lamp 165 Fender Lamp 175 Fender Lamp 180 Fender Lamp 1800 Fender Lamp 1805 Fender Lamp 235 w/ Flat Top Fender 245 w/ Flat Top Fender 255 w/ Flat Top Fender 2640 Fender Lamp 265 w/ Flat Top Fender 2675 Fender Lamp 2705 Fender Lamp 2745 Fender Lamp 275 w/ Flat Top Fender 2775 Fender Lamp 2805 Fender Lamp 285 Fender Lamp 3505 Fender Lamp 3525 Fender Lamp 3545 Fender Lamp MF30 Fender Lamp

Minneapolis Moline

Tractor: A4T1400 Fender Lamp A4T1600 Fender Lamp G1000 Fender Lamp G1000 Vista Fender Lamp G1050 Fender Lamp G1350 Fender Lamp G1355 Fender Lamp G707 Fender Lamp G708 Fender Lamp G750 Fender Lamp G900 Fender Lamp G950 Fender Lamp G955 Fender Lamp Jet Star 3 Fender Lamp M670 Fender Lamp M670 Super Fender Lamp U302 Fender Lamp

Oliver

Tractor: 1550 Fender Lamp 1555 Fender Lamp 1650 Fender Lamp 1655 Fender Lamp 1750 Fender Lamp 1800 Fender Lamp, Eff. S/N 90525 1850 Fender Lamp, Eff. S/N 150421 1855 Fender Lamp 1870 Fender Lamp 1950 Fender Lamp, Eff. S/N 150421 1950T Fender Lamp, Eff. S/N 194080 1955 Fender Lamp 2050 Fender Lamp, Eff. S/N 204001 2150 Fender Lamp, Eff. S/N 204001 2155 Fender Lamp 2255 Fender Lamp 2270 Fender Lamp 2655 Fender Lamp

White

Tractor: 140 160 185 2-105 Fender Lamp 2-150 Fender Lamp 2-62 Fender Lamp 2-78 Fender Lamp 2-85 Fender Lamp 4-150 Fender Lamp 4-180 Fender Lamp 4-78 Fender Lamp
