30 watt PAR-36 Hi-Lo, Frosted Lens

Be the first to review this product

High power PAR-36 size replacement LED light for the old style sealed beam halogen light. 6 x 5 watt CREE LED chips. Actual power use is around 22 watt, effective lumen around 1700 Hi-Lo Beam, 800 low beam. Note: It is a good practice to drill a few holes on top and bottom of the housing the light is mounted in, this will help the lights cool.

SKU: LL0028

Availability:

440 in stock

$38.00

Qty:

+ -

Notes:

All prices are USD. If imported into Canada/Internationally there will be brokerage costs collected by the carrier. Check the"Canada/World" link at the top of the page for more info. Please note that Hy-Capacity items can not be shipped to Canada / International.

Overview

PAR-36 led bulb / light, Hi-Lo beam

UV resistant PC lens.

Works as a replacement for the halogen sealed beam PAR-36 (4 3/8" bulb) used on many older tractors,

JD 30, 40 & 50 series. IH and many others.

6 Pcs * 5W LED CREE XTE 5

Color Temperature: 5000k (White daylight)
Hi-Lo beam
PC lens
Power: 30W rated, 19-20 watt used @12 V
Operating Voltage:9-32V DC
Luminous: High beam 1700 effective measured by machine
Current: 1.5A @ 12V
Lifespan: 30,000Hours +
Overvoltage protection
Back of housing has large cooling ribs for optimized heat dissipation
Size: 4.5" Dia.
IP67

HO Par36, HO Par-36, Par-36, Par36, High Output, High, Hi-Lo, RE25126

PAR-36 led bulb / light, Hi-Lo beam

UV resistant PC lens.

Works as a replacement for the halogen sealed beam PAR-36 (4 3/8" bulb) used on many older tractors,

JD 30, 40 & 50 series. IH and many others.

6 Pcs * 5W LED CREE XTE 5

Color Temperature: 5000k (White daylight)
Hi-Lo beam
PC lens
Power: 30W rated, 19-20 watt used @12 V
Operating Voltage:9-32V DC
Luminous: High beam 1700 effective measured by machine
Current: 1.5A @ 12V
Lifespan: 30,000Hours +
Overvoltage protection
Back of housing has large cooling ribs for optimized heat dissipation
Size: 4.5" Dia.
IP67

HO Par36, HO Par-36, Par-36, Par36, High Output, High, Hi-Lo, RE25126
